Valve

Swagelok SS-43GS6

SKU: 2009

În Stoc

Livrare 24/7 posibilă

Utilizat
Obținut din mediu de lucru

Fără TVA: €65,00 (1 disponibil)

Incl. TVA: €78,65

Prices exclude VAT. Contact us for bulk pricing or custom configurations.

Important: All warranties are our own warranties and do not cover factory or manufacturer warranties.

Perioade de garanție în funcție de condiții

Nou 12 luni

Recondiționat 3 luni

Utilizat DOA

We are not an authorized distributor, representative, or affiliate of any manufacturer or brand listed on this website

Attribute	Value
Ball/Stem Material	Stainless Steel
Body Material	316 Stainless Steel
Cleaning Process	Standard Cleaning and Packaging (SC-10)
Connection 1 Size	3/8 in.
Connection 1 Type	Tube Fitting
Connection 2 Size	3/8 in.
Connection 2 Type	Tube Fitting
CV Maximum	1.5
Flow Path	Standard
Flow Pattern	2-Way, Shutoff, Straight
Handle Color	Black
Handle Style	Lever
Low Emissions Certified	Yes
Orifice	0.187 in /4.7 mm
Packing Material	Modified PTFE UHMWPE
Ring/Disc Material	Stainless Steel
Room Temperature Pressure Rating	3000 PSIG @ 100°F /206 BAR @ 37°C
Testing	Testing according to WS-22
